Details & Features

• Triple-Choice™ Element
• Sear away mediocrity. The 12"/9"/6" Triple-Choice™ Element reaches a powerful 3,000 watts when all three tiers are activated, allowing you to experience ultimate versatility in power levels and heating efficiency.
• Oblivion Glass Surface
• Plunge into the tranquility of smooth, shadow-black glass that lures you in-and wipes down easily.
• Halo-Effect Knobs
• A halo of luminary LEDs glows softly when the element is on.
• True Flush Installation
• Pique curiosity. A true flush installation makes the Oblivion Glass surface melt into its surroundings, luring you in.
• Install Over Single Wall Oven
• Versatility and functionality converge with the ability to install in a countertop above our single wall oven.
• Radiant Elements
• Waiting expectantly beneath the stillness of shadow-black glass, electric elements are coiled to deliver heat upon command.
• Simmer Function
• Provides the optimal temperature for gently cooking delicate sauces and foods.
• Melt Function
• Ribbons of molten chocolate. Butter that yields to your knife. All elements are at your beck and call, ready to melt and soften with delicate heat that ignites passionate appetites.
• 6" 1,200-Watt Single Element
• A fast-heating and perfectly sized element for your small sauce pans and larger sauciers.
• 6" 1,300-Watt Single Element
• A fast-heating, perfectly sized and powerful 1,300-watt element for your small sauce pans and larger sauciers.
• 10"/6" Dual-Choice™ Element
• This two-tiered single element accommodates various-sized cookware in one location and can achieve an output of 3,000 watts when both elements are active.
• Hot Surface Indicators
• Light(s) positioned at the controls instantly show which element is still hot -- even if the element has been turned off.
• Power On Indicator Light
• See at a glance that power is on for an electric radiant element.
• Experts at the Ready
• Our crew relentlessly engages with JennAir™ appliances day in, day out. Initiated in rigorous product, process and culinary training, this team answers to you-from sales to installation to ownership.
• Serviced by a Select Few
• We narrowed down our dedicated network to only the most experienced providers. Armed with extensive access to products and knowledge, their expertise is unmatched.
• ADA Compliant
• Designed to meet ADA standards when installed according to the ADA guidelines.

Tech Specs

Dimensions
Depth	21 3/4
Width	30 13/16
Height	6 1/16
Carton Depth	25
Carton Height	10 1/4
Carton Width	35
Cutout Depth	20 3/8
Cutout Width	29 1/16
Gross Weight	46
Maximum Height	6 1/16
Net Weight	41.0
Certifications
Prop 65	Standard
ADA Compliant	ADA Height and Operation Compliant
UL	UL
Description
Combinations with Oven	JJW2427,JJW2430,JJW3430
Size (in.)	30
Configuration and Overview
Cooktop Type	Traditional
Fuel Type	Electric Radiant
Size (IN,inches)	30
Installs Over Built-In Oven	Yes
LP Convertible	No
Power Boost	No
Cooktop Details
Hot Surface Indicator Light	Yes
Cooktop Element Style	Radiant
Automatic Pan Detection	No
Downdraft Vent	No
Heating Element On Indicator Light	Yes
Cooktop Surface Color	Black
Number of Cooking Element-Burners	4
Left Front Element-Burner Size	6"
Cooktop Surface Material	Glass
Number of Open Bays	NA
Left Front Element-Burner Power	1300W
Left Front Element-Burner Type	Standard
Left Rear Element-Burner Power	3000/1900W
Right Rear Element-Burner Size	6"
Left Rear Element-Burner Size	10"/6"
Right Front Element-Burner Power	3000W/2200W/1100W
Right Front Element-Burner Size	12"/9"/6"
Right Front Element-Burner Type	Triple
Right Rear Element-Burner Power	1200W
Right Rear Element-Burner Type	Standard
Cooktop Configuration	All Burners
Left Rear Element-Burner Type	Dual
Controls
Control Type	Knobs
Knob Color	Black Stainless
Knob Type	Metal
Control Location	Right
Appearance
Digital Display	No
Features
Griddle	NA
Power Outage Compatible	No
Electrical
Amps	40
Power Cord Included	No
Volts	240
208V Compatible	Yes
Hz	60
Refinement
Style	Cooktops
Design Type
Design Expression	Oblivian Glass
Energy
Annual Energy Usage [kWh]	258
