36" Custom Hood Liner

Jenn-Air JXL6536HSS

36" Custom Hood Liner

Goemans' Web Price
as of Oct, 02 2022

Extended Warranty

Total Price:
Show available promotions
  • Add to compare
  • Add to wishlist

Buy Now, Pay Later

No interest and monthly payments of only $63 if balance is paid in full within 12months. Plus applicable fees and taxes. See in store for details.

Details & Features

This custom hood liner features a hidden ventilation system mounted to the inside of a custom vent cover (which can be made of metal, wood, plaster or tile), offering a uniquely streamlined look. It also offers you a choice of motors for different levels of ventilation power.

  • Optional 600 CFM or 1,200 CFM Internal Blower
    • Three-speed blower - ordered separately - rapidly rids the air of smoke, steam and cooking odors so the air is fresh and clean.
  • Optional 1,200 CFM In-Line Blower
    • Quickly removes smoke, steam and cooking odors from the kitchen and mounts further down the duct run to help reduce the noise of the ventilation system in the kitchen.
  • 10-Inch Round Exterior Venting
    • Large-diameter venting that enables quiet airflow and effective performance.
  • Dishwasher-Safe Stainless Steel Baffle Filters
    • These stainless steel baffle filters, which effectively capture smoke, grease and cooking odors as they''re drawn through the hood, can be easily cleaned in the dishwasher.
  • Custom Hood Liner
    • This hidden ventilation system mounts to the inside of a custom-built vent covering that can blend into the kitchen's design or be highlighted as a visual feature of the kitchen.
  • Lustre Stainless
    • Blur the lines of temptation with mind-bending curves and hairpin corners of stainless steel that will leave you reeling.
  • Two Lighting Levels
    • Two different settings give you the appropriate level of lighting as you cook.
  • Halogen Task Lighting
    • Twice as energy-efficient and longer-lasting than incandescent light bulbs, these halogen lights beautifully illuminate the cooking surface from above.
  • Knob ControlsFeature Short:Knob Controls
    • Knob controls provide precise adjustment and easy selection of ventilation speeds.
  • Versatile Installation Options
    • Allow for island- or wall-mount installations for kitchen customization and a unique look.
  • Three Fan Speed Settings
    • Provides a range of ventilation power to accommodate your precise cooking needs.
  • Badasses at the Ready
    • Our crew relentlessly engages with JennAir™ appliances day in, day out. Initiated in rigorous product, process and culinary training, this team answers to you-from sales to installation to ownership.
  • Serviced by a Select Few
    • We narrowed down our dedicated network to only the most experienced providers. Armed with unprecedented access to products and knowledge, their expertise is unmatched.
  • Auto Sense Option
    • Automatically turns the ventilation system on and adjusts power as needed.

Tech Specs

Depth 22
Width 35 7/8
Height 11 1/2
Carton Depth 27 9/16
Carton Height 16 5/8
Carton Width 41 3/8
Gross Weight 50
Net Weight 31.7
Prop 65 Standard
Energy Star® Qualified No
UL Yes
Configuration and Overview
Hood Type Custom Hood Liners
Size (in.) 36
Control Type Knobs
Night Light Type Halogen
Number of Night Light Settings 1
Task Lighting Yes
Number of Task Light Settings 1
Night Light Yes
isBaseUnit true
isConsumerUnit true
IsInvoiceUnit true
IsOrderableUnit true
Product Type EA
GPC Code 10005322
UDEX 1100642102
Ventilation System
Duct Type Round
Filters Grease Filters
Blower Motor Blower Motor to be Purchased Separately
Duct Outlet Size (in.) 10
Venting Exterior
Number of Speeds 3
Task Light Type Halogen
Material Stainless Steel
Amps 15
Power Cord Included Yes
Refinement JEN
Ventilation CFM Rating 1200
Style Hoods
Design Type
Design Expression Stainless Steel
